| Frame |
Pacific Reach AL7005 flat welding w/unified rear triangle O.L.D.135mm , elastomer suspension PU 90D red 25.6mm travel , Max chain ring size for FD 53T |
| Fork |
Pacific Reach AL6061 flat welding w/open fork end 15×100mm thru axle , elastomer suspension PU R:80D yellow/L:90D red 12.3mm travel |
| Headsets |
Reach tapered integrated threadless headset top 1-1/8" bottom 1-1/4" black |
| Stem riser |
Reach exclusive Φ28.6mm / 215mm sandblast black |
| Seatpost |
34.9×400mm hard anodized black AL6061 w/ laser scale |
| Disc rotor |
140mm (not included) |
| Weight |
4.0kg (frame/fork/stem riser/seat clamp ) |
| Rider height |
145~185cm |
| Max load |
110kg(rider w/luggage) |
